Описание
Материал делителя: алюминий.
Волновое сопротивление: 50 Ом
КСВН (макс.): 1.15
Технические параметры делителей мощности:
| Модель
|
Диапазон частот, МГц
|
Количество выходов
|
Тип ВЧ разъема
|
Потери при делении, дБ
|
| TR2201
|
68…88
|
2
|
N female
|
3,01
|
| TR3201
|
68…88
|
3
|
N female
|
4,77
|
| TR4201
|
68…88
|
4
|
N female
|
6,02
|
| TR2202
|
68…88
|
2
|
7/16 female
|
3,01
|
| TR3202
|
68…88
|
3
|
7/16 female
|
4,77
|
| TR4202
|
68…88
|
4
|
7/16 female
|
6,02
|
| TR2301
|
88…108
|
2
|
N female
|
3,01
|
| TR3301
|
88…108
|
3
|
N female
|
4,77
|
| TR4301
|
88…108
|
4
|
N female
|
6,02
|
| TR2302
|
88…108
|
2
|
7/16 female
|
3,01
|
| TR3302
|
88…108
|
3
|
7/16 female
|
4,77
|
| TR4302
|
88…108
|
4
|
7/16 female
|
6,02
|
| TR8302
|
88…108
|
8
|
7/16 female
|
9,03
|
| TR2351
|
118…144
|
2
|
N female
|
3,01
|
| TR3351
|
118…144
|
3
|
N female
|
4,77
|
| TR4351
|
118…144
|
4
|
N female
|
6,02
|
| TR2352
|
118…144
|
2
|
7/16 female
|
3,01
|
| TR3352
|
118…144
|
3
|
7/16 female
|
4,77
|
| TR4352
|
118…144
|
4
|
7/16 female
|
6,02
|
| TR2361
|
108…225
|
2
|
N female
|
3,01
|
| TR3361
|
108…225
|
3
|
N female
|
4,77
|
| TR4361
|
108…225
|
4
|
N female
|
6,02
|
| TR2362
|
108…225
|
2
|
7/16 female
|
3,01
|
| TR3362
|
108…225
|
3
|
7/16 female
|
4,77
|
| TR4362
|
108…225
|
4
|
7/16 female
|
6,02
|
| TR2401
|
146…174
|
2
|
N female
|
3,01
|
| TR3401
|
146…174
|
3
|
N female
|
4,77
|
| TR4401
|
146…174
|
4
|
N female
|
6,02
|
| TR2402
|
146…174
|
2
|
7/16 female
|
3,01
|
| TR3402
|
146…174
|
3
|
7/16 female
|
4,77
|
| TR4402
|
146…174
|
4
|
7/16 female
|
6,02
|
| TR2451
|
174…230
|
2
|
N female
|
3,01
|
| TR2452
|
174…230
|
2
|
7/16 female
|
3,01
|
| TR2481
|
225…400
|
2
|
N female
|
3,01
|
| TR3481
|
225…400
|
3
|
N female
|
4,77
|
| TR4481
|
225…400
|
4
|
N female
|
6,02
|
| TR2482
|
225…400
|
2
|
7/16 female
|
3,01
|
| TR3482
|
225…400
|
3
|
7/16 female
|
4,77
|
| TR4482
|
225…400
|
4
|
7/16 female
|
6,02
|
| TR2501
|
340…470
|
2
|
N female
|
3,01
|
| TR3501
|
340…470
|
3
|
N female
|
4,77
|
| TR4501
|
340…470
|
4
|
N female
|
6,02
|
| TR2502
|
340…470
|
2
|
7/16 female
|
3,01
|
| TR3502
|
340…470
|
3
|
7/16 female
|
4,77
|
| TR4502
|
340…470
|
4
|
7/16 female
|
6,02
|
| TRIN2502
|
380…430
|
2
|
N female
|
3,01
|
| TRIN2502-7
|
380…430
|
2
|
N female
|
1,0/7,0 uneven
|
| TRIN2502-12
|
380…430
|
2
|
N female
|
0,3/12 uneven
|
| TRIN2502-20
|
380…430
|
2
|
N female
|
0,05/20 uneven
|
| TRL2502
|
380…430
|
2
|
7/16 female
|
3,01
|
| TRL2502-7
|
380…430
|
2
|
7/16 female
|
1,0/7,0 uneven
|
| TRL2502-12
|
380…430
|
2
|
7/16 female
|
0,3/12 uneven
|
| TRL2852
|
380…2200
|
2
|
7/16 female
|
3,01
|
| TR3852
|
380…470,
870…960 1710…2170 |
3
|
7/16 female
|
4,77
|
| TR4952
|
380…470, 870…960,
1710…2170 |
4
|
7/16 female
|
6,02
|
